Safe & reliable way to power multiple cameras simultaneously.

The ESPER PowerBox provides protected, regulated and reliable power for up to 6 cameras from a single outlet and for less than the cost of the manufacturer’s AC power adapters. Perfect for photogrammetry set-ups, bullet-time photography and all other multi-camera applications. Works worldwide.

Array
(
    [0] => Array
        (
            [acf_fc_layout] => foo_gallery
            [foo_gallery_header] => Powered using ESPER PowerBox
            [foo_gallery_shortcode] =>



            [foo_gallery_supporting_link_text] => Other multi-camera setup examples powered with ESPER PowerBox
            [foo_gallery_supporting_link] => https://www.esperhq.com/dev/customer_gallery/
            [foo_gallery_background_colour] => black
        )

    [1] => Array
        (
            [acf_fc_layout] => features_block
            [features] => Array
                (
                    [0] => Array
                        (
                            [icon] => multi-camera
                            [heading] => Powering multi-camera set-ups
                            [content] =>

The PowerBox has been designed for any set-up that requires the safe and reliable powering of multiple cameras simultaneously.

) [1] => Array ( [icon] => worldwide [heading] => It works. Worldwide [content] =>

The PowerBox multi camera power supply works worldwide and accepts voltages of 100-250V at frequencies between 50-60Hz.

) [2] => Array ( [icon] => intelligent-trip [heading] => Intelligent trip and reset [content] =>

If there’s an issue with any of the connected cameras the PowerBox intelligently isolates the connection allowing you to reset only the affected output. No need to reboot all the other cameras, saving time and the potential for other issues to arise.

) [3] => Array ( [icon] => regulated-power [heading] => Fully regulated and protected power [content] =>

The PowerBox mimics the operation of Li-ion camera batteries and outputs 9VDC from the output sockets. It connects to multiple cameras via DC Couplers (dummy batteries). These vary depending on the make and model of camera and we can supply DC Couplers for most cameras.

) [4] => Array ( [icon] => powers-camera [heading] => Powers any combination of compatible cameras [content] =>

The PowerBox can be used with any combination of compatible cameras – see below

) ) ) [2] => Array ( [acf_fc_layout] => product_specs_block [heading] => [type] => single_product [background_colour] => grey [specs] => Array ( [0] => Array ( [button_text] => Front [image_key_map] => {"image":"https://www.esperhq.com/wp-content/uploads/2018/04/Product-Images_0001_Powerbox-Side-B.jpg","height":1016,"width":1200,"annotations":[{"x":27,"y":56,"title":"Input : 48VDC lockable 4 Pin DIN"},{"x":47,"y":56,"title":"Reset Switch "},{"x":59,"y":57,"title":"Fuse"},{"x":77,"y":72,"title":"Output : USB-C 5VDC Power Output max current 3A"}]} [specifications] => Array ( [heading] => Technical Spec [description] => [items] => Array ( [0] => Array ( [attribute] => Dimensions [detail] => 113mm w x 40mm h x 175mm d ) [1] => Array ( [attribute] => Weight [detail] => 685g ) [2] => Array ( [attribute] => Enclosure [detail] => High Impact Lexan Polycarbonate with 5251 Aluminium Face Plates ) [3] => Array ( [attribute] => Enclosure Finish [detail] => Matt Black Textured ) [4] => Array ( [attribute] => Face Plate Finish [detail] => Matt Black Anodised ) [5] => Array ( [attribute] => Power output [detail] => 9VDC from the outputs sockets ) ) [content] => ESPER Powerboxes and TriggerBoxes have been designed to stack neatly together. ) ) [1] => Array ( [button_text] => Rear [image_key_map] => {"image":"https://www.esperhq.com/wp-content/uploads/2018/04/Product-Images_0000_Powerbox-Side-A.jpg","height":1016,"width":1200,"annotations":[{"x":15,"y":71,"title":"Outputs : 6 x 9VDC outputs on 2.1mm DC Jacks for connecting cameras via DC Couplers"},{"x":73,"y":75,"title":"Short Circuit Warning Lights : 6 x LEDs for advising of cable, coupler or camera problem."}]} [specifications] => Array ( [heading] => Technical Spec [description] => [items] => Array ( [0] => Array ( [attribute] => Dimensions [detail] => 113mm w x 40mm h x 175mm d ) [1] => Array ( [attribute] => Weight [detail] => 685g ) [2] => Array ( [attribute] => Enclosure [detail] => High Impact Lexan Polycarbonate with 5251 Aluminium Face Plates ) [3] => Array ( [attribute] => Enclosure Finish [detail] => Matt Black Textured ) [4] => Array ( [attribute] => Face Plate Finish [detail] => Matt Black Anodised ) [5] => Array ( [attribute] => Power output [detail] => 9VDC from the outputs sockets ) ) [content] => ESPER Powerboxes and TriggerBoxes have been designed to stack neatly together. ) ) ) [whats_included] => Array ( [0] => Array ( [item] => ESPER PowerBox ) [1] => Array ( [item] => Multi-region universal power supply ) [2] => Array ( [item] => 2m IEC C13 cable ) ) ) [3] => Array ( [acf_fc_layout] => case_studies [case_studies_header] => [case_studies_introduction] => [case_studies] => Array ( [0] => 2955 [1] => 2969 [2] => 2967 ) [case_studies_revised] => Array ( [0] => Array ( [title] => [summary] => [post] => 2955 ) [1] => Array ( [title] => [summary] => [post] => 2969 ) [2] => Array ( [title] => [summary] => [post] => 2967 ) ) ) [4] => Array ( [acf_fc_layout] => reviews_block ) [5] => Array ( [acf_fc_layout] => faq_block [faq_item] => Array ( [0] => Array ( [faq] => Array ( [0] => 4077 [1] => 4084 [2] => 4083 [3] => 4079 [4] => 4080 [5] => 4078 ) ) ) ) [6] => Array ( [acf_fc_layout] => testimonial_block [testimonial] => Array ( [0] => WP_Post Object ( [ID] => 153 [post_author] => 1 [post_date] => 2018-04-24 16:03:45 [post_date_gmt] => 2018-04-24 15:03:45 [post_content] => [post_title] => ERIC PARÉ. [post_excerpt] => [post_status] => publish [comment_status] => closed [ping_status] => closed [post_password] => [post_name] => eric-pare [to_ping] => [pinged] => [post_modified] => 2019-06-21 14:52:19 [post_modified_gmt] => 2019-06-21 13:52:19 [post_content_filtered] => [post_parent] => 0 [guid] => https://www.esperhq.com/?post_type=testimonial&p=153 [menu_order] => 0 [post_type] => testimonial [post_mime_type] => [comment_count] => 0 [filter] => raw ) ) ) [7] => Array ( [acf_fc_layout] => compatibility_block [heading] => Camera Compatibility [content] =>

The PowerBox has been designed to work with APS-C / cropped frame cameras that operate from 7.4v Li-ion batteries. Compatibility with higher current drawing cameras such as full frame models is achievable however in some cases you may not be able to use all the available power outlets of the PowerBox. Please contact us to discuss your requirements.

[images] => Array ( [0] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/04/canon.png ) [1] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/04/fujifilm.png ) [2] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/04/machineVisionCompatible.png ) [3] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/04/nikon.png ) [4] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/04/panasonic.png ) [5] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/07/512px-Phase_One_logo.svg.png ) [6] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/04/sony.png ) [7] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/12/olympus-logo.png ) [8] => Array ( [image] => https://www.esperhq.com/dev/wp-content/uploads/2018/12/pentax-logo.png ) ) ) [8] => Array ( [acf_fc_layout] => cta_block [heading] => Ready to order? [cta_type] => scroll_to [content] =>

The ESPER PowerBox is available shipped and supported worldwide. Click on the below button to configure your order.

[button_text] => Order Now [scroll_to_target] => .product-template-default [button_form] => [enable_padding_top] => 1 [enable_padding_bottom] => 1 ) )

Features & Functionality

Powering multi-camera set-ups

The PowerBox has been designed for any set-up that requires the safe and reliable powering of multiple cameras simultaneously.

It works. Worldwide

The PowerBox multi camera power supply works worldwide and accepts voltages of 100-250V at frequencies between 50-60Hz.

Intelligent trip and reset

If there’s an issue with any of the connected cameras the PowerBox intelligently isolates the connection allowing you to reset only the affected output. No need to reboot all the other cameras, saving time and the potential for other issues to arise.

Fully regulated and protected power

The PowerBox mimics the operation of Li-ion camera batteries and outputs 9VDC from the output sockets. It connects to multiple cameras via DC Couplers (dummy batteries). These vary depending on the make and model of camera and we can supply DC Couplers for most cameras.

Powers any combination of compatible cameras

The PowerBox can be used with any combination of compatible cameras – see below

Front
1
2
3
4
Rear
1
2

Technical Spec

  • Input : 48VDC lockable 4 Pin DIN
  • Reset Switch
  • Fuse
  • Output : USB-C 5VDC Power Output max current 3A
  • Dimensions

    113mm w x 40mm h x 175mm d

  • Weight

    685g

  • Enclosure

    High Impact Lexan Polycarbonate with 5251 Aluminium Face Plates

  • Enclosure Finish

    Matt Black Textured

  • Face Plate Finish

    Matt Black Anodised

  • Power output

    9VDC from the outputs sockets

What's Included

  • ESPER PowerBox

  • Multi-region universal power supply

  • 2m IEC C13 cable

ESPER Powerboxes and TriggerBoxes have been designed to stack neatly together.

Technical Spec

  • Outputs : 6 x 9VDC outputs on 2.1mm DC Jacks for connecting cameras via DC Couplers
  • Short Circuit Warning Lights : 6 x LEDs for advising of cable, coupler or camera problem.
  • Dimensions

    113mm w x 40mm h x 175mm d

  • Weight

    685g

  • Enclosure

    High Impact Lexan Polycarbonate with 5251 Aluminium Face Plates

  • Enclosure Finish

    Matt Black Textured

  • Face Plate Finish

    Matt Black Anodised

  • Power output

    9VDC from the outputs sockets

What's Included

  • ESPER PowerBox

  • Multi-region universal power supply

  • 2m IEC C13 cable

ESPER Powerboxes and TriggerBoxes have been designed to stack neatly together.

Customer Reviews

Customer Reviews
4.8 Based on 31 Reviews
5 ★
84%
26
4 ★
13%
4
3 ★
3%
1
2 ★
0%
0
1 ★
0%
0
Customer Photos
Write a Review Ask a Question

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
  • Esper
  • power
  • cables
  • connection
  • cameras
  • Support
  • issues
  • everything
  • some
  • team
A
23/07/2023
Anonymous
DE DE

great addition to your bullet-time setup

great service and support. very clever piece of equipemtn for your bullet-time setup.

08/08/2023

ESPER

Thank you for your review! We're happy to hear that you are pleased with the service and support. Thanks, Luke

HK
09/06/2023
Hendrik K.
NL NL

Excellent: I would definitely buy from you again.

Excellent: I would definitely buy from you again.

28/06/2023

ESPER

Thank you for your review. We appreciate the feedback.

A
06/06/2023
Anonymous
DE DE

great product and amazing support!

great product and amazing support!

28/06/2023

ESPER

Thank you so much for your review and kind feedback!

A ESPER Customer
MW
25/05/2023
Mathis W.
DE DE

Easy to handle

We choose the Power and Trigger Box. TriggerBox is nice to have the power box is very well, easy to handle and you don't have many cables.

25/05/2023

ESPER

Hi Mathis, Thank you for your review! We really appreciate it and are happy to hear how the TriggerBox and PowerBox have helped you - Luke

A
26/02/2022
Anonymous
GT GT

Best of the best

Esper has been an excellent acquisition. Works perfect.

FAQs

What voltages does the PowerBox accept?

The PowerBox works worldwide and accepts voltages of 100-250V at frequencies between 50-60Hz.

What is the output voltage of the PowerBox?

The PowerBox has an output stage designed to mimic Li-ion camera batteries the output voltage is regulated at 9VDC.

What are the applications for the PowerBox?

Any application that requires the reliable powering of multiple cameras simultaneously.

Will my cameras be compatible with the Esper PowerBox?

The PowerBox is designed to power the camera models that are most commonly used in multi camera arrays. Typically these are cropped sensor Canon or Nikon DSLRs.  Please contact us if you want to check compatibility with specific models.

Can a combination of different cameras be used with the PowerBox?

Yes, the PowerBox can be used with any combination of compatible cameras.

How do the cameras connect to the PowerBox?

The power connection to the cameras is via DC Couplers (dummy batteries) these vary depending on the make and model. We can supply DC couplers for most commonly used cameras please contact us for pricing and availability.

Esper have been powering our bullet-time rigs for a long time now. We can’t really imagine how we could survive without their PowerBox products.

ERIC PARÉ. | Xangle

Camera Compatibility

The PowerBox has been designed to work with APS-C / cropped frame cameras that operate from 7.4v Li-ion batteries. Compatibility with higher current drawing cameras such as full frame models is achievable however in some cases you may not be able to use all the available power outlets of the PowerBox. Please contact us to discuss your requirements.
